BIGTREETECH EBB36 Can V1.2
$ 98.57
- BIGTREETECH EBB36 Can V1.2BIGTREETECH EBB36 or EBB42 CAN is a nozzle adapter board specially designed for a 36 or 42 stepper motor extruder, which is launched by the 3D printing team Shenzhen Big Tree Technology Co., Ltd. It can communicate via USB or CAN, which will greatly simplify the wirings.BIGTREETECH EBB36 Main Features: With BOOT and RESET buttons reserved, users can update the firmware via DFU mode by USB.Added protection circuit on the thermistor avoids burning the main control chip caused by leakage current from the heating rod.Users can select the thermistor’s pull-up resistor values through a jumper wire, so as to support PT1000 (2.2K pull-up resistors), which makes it convenient for DIY.Connect the USB with a jumper cap to get it powered on, which effectively isolates the main control board DC-DC from USB 5V.Reserved I2C interface allows for filament broke and clogged detection, and supports other DIY functions.Added anti-flyback diodes on the heating rod and fans’ ports effectively protect the MOS tube from being burned due to reverse voltage.Anti-reverse connection protection on the power interface prevents users from burning the motherboard when mistakenly connecting the reverse power line during DIY.Onboard MAX31865 supports selecting 2-wire or 4-wire of PT100/ PT1000.Supports communication via CAN or USB. The terminal resistor 120R of CAN can be selected through the jumper cap, and it reserves CAN expansion interfaces.Equipped ESD protection chip on the USB port prevents the main control board from being broken down by the static electricity of the USB port. The adaptor board is equipped with terminals, female reeds, double-way studs and screws, which are required for DIY, greatly meeting the DIY needs of customers.Specifications:MCU: ARM Cortex-M0 STM32F072C8T6 48MHz with CAN busStepper Driver: Onboard TMC2209 in UART mode, UART address: 00, Rsense: 0.11ROnboard Accelerometer Sensor: ADXL345Onboard Temperature IC: Max31865 Select 2 / 4 lines PT100 / PT1000 by DIP switch (no Max31865 verson have not this feature)Input Voltage: DC12V-DC24V 6ALogic Voltage: DC 3.3VHeating Interface: Hotend (E0), maximum output current: 5AFan Interfaces: two CNC fans (FAN0, FAN1)Maximum Output Current of Fan Interface: 1A, Peak Value 1.5AExpansion Interfaces: EndStop, I2C, Probe, RGB, PT100/PT1000, USB interface, CAN InterfaceTemperature Sensor Interface Optional: 1 Channel 100K NTC or PT1000(TH0), 1 Channel PT100/PT1000USB Communication Interface: USB-Type-CDC 5V Maximum Output Current: 1APackage Includes:1x BIGTREETECH EBB36 V1.2Documents:GitHubManualRelated Products:BIGTREETECH
