SFU2005 Ball Screw Machine Ending With Flange Nut – 2000mm
$ 94.46
- A ball screw is a mechanical linear actuator that translates rotational motion to linear motion with little friction. A threaded shaft provides a helical raceway for ball bearings which act as a precision screw. As well as being able to apply or withstand high thrust loads, they can do so with minimum internal friction. They are made to close tolerances and are therefore suitable for use in situations in which high precision is necessary. The ball assembly acts as the nut while the threaded shaft is the screw. In contrast to conventional lead screws, ball screws tend to be rather bulky, due to the need to have a mechanism to re-circulate the balls bearing.Specification:Product Name: Ball ScrewManufacturing Process: Rolled Thread;Precision: C7 GradeMaterial: Carbon SteelModel: SFU2005Diameter of rod: 20mmLead: 5mm.Length: 2000mm
